Easy Assemble Solar Panel Installer Tools Hoist Ladder for Residential PV Installations

Application scenarios

This equipment is an assembled adjustable angle on-site designed incline lift. Mainly used in logistics, express delivery, Home improvement, moving, rural self-built houses and other industries, as well as labor

Factory equipment handling, not for carrying people. The operator must first understand the performance and operation of this equipment operating principle, correctly assemble, operate and maintain according to the instructions, Wear necessary safety protective equipment (such as wearing a hard hat, safety shoes, etc.). During the running process, alarms should be set around the stairs as shown in the figure

Line, leave immediately after the goods are placed, there may be dangerous

People are strictly prohibited in the area.

Technical Description

Do not exceed 19 meters of track length for inclined placement. After assembly, the upper and lower parts of the ladder track must be connected firmly. The aluminum rails are inserted into each other front and rear and fastened with special horseshoe screws and wing nuts without tools. A limit switch must be installed at the appropriate position on the top of the lift, and the motor will automatically stop when the load platform reaches the appropriate position. The foot ladder section is marked with an angle and a reference to the load capacity table at different heights and angles, which should not exceed the values in the table. The turning component is a non-essential component and is used in places where turning is required (such as sloped eaves) and when entering buildings. The turning assembly can change the direction of the slide rail assembly and the load platform, and the angle adjustment range: 20°-45°. The inclined section after turning can be equipped with multiple inclined roof support bracket parts or high support parts, which are not required but recommended. The height of the inclined roof bracket is adjustable, and the height is adjusted from 370mm-600mm. The high support assembly bracket is adjustable in height, ranging from 0-550mm. The intermediate support component is a non-essential unit, equipped with an intermediate support to improve the stability of the lift and adjust the height from 4 m- 5.7m.
