| Rated load capacity： | 2000kg |
| Forks dimensions： | 65/190/1150 |
| Operation： | Rider type |
| Price: | 26535.65Dollar/sets |
| Min.Order: | 1 sets |
| Supply | 1000 sets |
| Delivery: | Shipment within 30 days since the date of payment |
| Address: | China Anhui |
| Valid until: | Never Expire |
| Updated on: | 2025-07-16 16:19 |
| Views: | 4 |
South Second Ring Road, Shushan District, Hefei City, Anhui Province
Equipped with branded control system and multi-functional protection system, it offers higher level functional safety;
Equipped with vertical branded gear box, multi-functional solutions and flexible module construction system. Optimized gear meshing technology can reduce the noise and offer high performance and efficiency;
EPS steering energy reduces 20% with accurate operation, flexible steering, relieving operators pressures and greatly improving the production ability;
No need to adjust the buffering spring. It can adjust the vertical drive unit according to road conditions, increasing the steady operation efficiency;
High quality with buffering hydraulic system. Low noise, light shock, good seal, steady lift and lower processes;
Equipped with full AC drive system, small volume, light weight, high efficiency, free-maintenance and carbon-brush replacement. No more maintenance and protection;
Wide field mast design, specialized groove steel with high strength;
| Characteristic | 1.1 | Model | CDD101I-30 | CDD1511-30 | CDD2011-30 | |
| 1.2 | Power(electricity,diesel,LPG,petrol,manual) | Full electric | Full electric | Full electric | ||
| 1.3 | Operation(manual,walkie,side-standing,picker) | Rider type | Rider type | Rider type | ||
| 1.4 | Rated load capacity | Q(kg) | 1000 | 1500 | 2000 | |
| 1.5 | Load center distance | C(mm) | 500 | 500 | 500 | |
| 1.6 | Load bearing distance | X(mm) | 676 | 676 | 676 | |
| 1.7 | Wheelbase | Y(mm) | 1430 | 1430 | 1430 | |
| Weight | 2.1 | Service weight(incl.battery) | kg | 1075 | 1115 | 1150 |
| Wheel/ Chassis | 3.1 | Wheel type (The front/rear) | PU | PU | PU | |
| 3.2 | Front wheel specification | ø×w(mm) | φ80x70 | φ80×70 | φ80×70 | |
| 3.3 | The rear wheel specification | ø×w(mm) | φ230x75 | φ230x75 | φ230x75 | |
| 3.4 | Tread,front | b2(mm) | 490 | 490 | 490 | |
| 3.5 | Tread,rear | b3(mm) | 658 | 658 | 658 | |
| Dimensions | 4.1 | Forks height,mast retracted | h(mm) | 2060 | 2060 | 2060 |
| 4.2 | Lift height | h1(mm) | 3000 | 3000 | 3000 | |
| 4.3 | Mast height,extended | h2(mm) | 3541 | 3541 | 3541 | |
| 4.4 | Handle height | h5(mm) | 1430 | 1430 | 1430 | |
| 4.5 | Forks height,mast retracted | h3(mm) | 86 | 86 | 86 | |
| 4.6 | Overall vehicle length(pallet folded/unfolded) | L(mm) | 2185/2605 | 2185/2605 | 2185/2605 | |
| 4.7 | Overall width | b1(mm) | 850 | 850 | 850 | |
| 4.8 | Forks dimensions | s/e/l(mm) | 65/190/1150 | 65/190/1150 | 65/190/1150 | |
| 4.9 | Forks outer distance | b5(mm) | 680 | 680 | 680 | |
| 4.10 | The min.ground clearance(Wheelbase center) | m2(mm) | 30 | 30 | 30 | |
| 4.11 | Stackingaislewidth,palletfolded1m×1.2m(1mcrossforks) | Ast(mm) | 2615 | 2615 | 2615 | |
| 4.12 | Stackingaislewidth,palletunfolded1m×1.2m(1mcross forks) | Ast(mm) | 3016 | 3016 | 3016 | |
| 4.13 | The min.turning radius(pallet folded/unfolded) | Wa(mm) | 1729/2130 | 1729/2130 | 1729/2130 | |
| Peformance | 5.1 | Travelling speed,unladen/full-loaded | km/h | 5.5/5 | 5.5/5 | 5.5/5 |
| 5.2 | Lift speed unladen/full-loaded | m/s | 0.11/0.1 | 0.1/0.09 | 0.1/0.086 | |
| 5.3 | Lowerspeed unladen/full-loaded | m/s | 0.082/0.112 | 0.082/0.115 | 0.082/0.123 | |
| 5.4 | The max.gradability,unladen/full-loaded | % | 8/6 | 8/6 | 8/4 | |
| 5.5 | Service brake | Electromagnetic | Electromagnetic | Electromagnetic | ||
| Motor | 6.1 | Drive motorpower | kw | 1.5 | 1.5 | 1.5 |
| 6.2 | Lift motor power | kw | 2.2 | 2.2 | 2.2 | |
| 6.3 | Battery type | Lead-acid | Lead-acid | Lead-acid | ||
| 6.4 | Battery voltage/capacity | V/Ah | 24/210 | 24/210 | 24/210 | |
| 6.5 | Charger | V/A | 24/30 | 24/30 | 24/30 | |
| Others | 7.1 | Drive controlmode | AC | AC | AC | |
| 7.2 | Noiselevel at driver's ears according to En12053 | dB(A) | 75 | 75 | 75 |
