CNC Vertical Lathe MachineFeatures:

1.This vertical CNC lathe is a advanced equipment of high performance, widely technology range, high production efficiency. CNC verticallathe is apply to machining of all industries. Rough and finish machining of inside＆out...

CNC Vertical Lathe MachineFeatures:

1.This vertical CNC lathe is a advanced equipment of high performance, widely technology range, high production efficiency. CNC verticallathe is apply to machining of all industries. Rough and finish machining of inside＆outside cylindrical surface, circular conical surface, end face, grooving, arc surface, sorts of curve face and thread

2.Worktable main spindle adopts high precision and adjustable radial clearance biserial short cylindrical roller bearing to centering to centering. Axial direction adopts CC hydrostatic guideway, worktable have the features of high running accuracy, big bearing capacity, small thermal deformation.

3.The lathe feed adopts AC servo motor, ball screw for drive. Rail head of cross beam equipped with close shield, increase the safety and the amenity

4.The lathe feed adopts AC motor drive, 16 steps main spindle speed change mechanism and realize the worktable range of speed

5.CNC system can select import or domestic according to user needs, CK51A series not have cover housing, CK51B series have cover housing, chip removal and cooling liquid recovery device

6. Vertical column, cross beam guideway all use high-frequnency, quenching, and the quenching hardness is HRC48-55

CNC Vertical Lathe Machine Technical Specifications:
